Lighting Towers
Portable Lighting Towers for Any Site
Light towers from OZWIDE deliver powerful, reliable illumination for mine sites, construction, civil works, events and emergency operations. The range runs from a 12,000 lumen solar street light up to a 345,600 lumen diesel lighting tower, with coverage to 12,600 m² at one lux, so there is a machine to suit the site, the fuel preference, the noise limit and the budget.
Choosing between them usually comes down to two questions: how long it has to run unattended, and how quiet it has to be.
Diesel
Proven power for continuous, round-the-clock lighting. Low voltage 48V DC models run their floodlights at up to 180 lumens per watt, around 25 percent more light than a mains voltage machine draws the same fuel to produce. Road trailer and compact site frame options. The workhorse choice for mining and civil projects.
| DIESEL MODELS→ | |||
| Model | Total lumens | Coverage (1 lux) | Run time |
| GLT6-A DC | 345,600 Lm | 11,100 m² | 200 h |
| GLT6-A | 276,000 Lm | 12,600 m² | 140 h |
| CUBE+ Hyper | 184,000 Lm | 10,700 m² | 243 h |
| GLT4 DC Hyper | 180,000 Lm | 10,700 m² | 257 h |
| CUBE DC Hyper | 180,000 Lm | 10,700 m² | 215 h |
Hybrid
A battery pack carries the load and the engine starts only to recharge, which cuts fuel burn, servicing and engine hours. Completely silent at 0 dB(A) on battery. Add solar panels and the interval between refuels stretches further again. Suits night works near housing and any site with a noise limit.
| HYBRID MODELS→ | ||||
| Model | Total lumens | Coverage (1 lux) | On battery | Between refuels |
| GLT4-A Hybrid Solar | 144,000 Lm | 7,500 m² | Silent, 0 dB(A) | Up to 700 h * |
| V20 PRO Hyper AGM | 139,200 Lm | 3,100 m² | Up to 19 h | Up to 471 h * |
Solar
Zero emission, silent, no refuelling and no cabling. Two machines, sized to the job. The VT-Solar Hydraulic Hyper gives 60,000 lumens over 2,800 m² from three 400 Wp panels and an 11.5 kWh battery, on a road trailer with a hydraulic 8.2 metre mast, for lighting work areas. The LP Solar Street Light is a compact self-igniting unit with a darkness sensor and motion sensor, built for car parks, footpaths, walkways and temporary access.
| SOLAR MODELS→ | ||||
| Model | Total lumens | Coverage (1 lux) | Run time | Recharge |
| VT-Solar Hydraulic Hyper | 60,000 Lm | 2,800 m² | Up to 50 h * | 8 h |
| LP Solar Street Light | 12,000 Lm | 950 m² | Up to 25 h | 7 h |
* Maximum run times are measured with the lamps dimmed to 25 percent. On the GLT4-A Hybrid Solar the figure also assumes the photovoltaic panels are correctly oriented, and will vary with latitude and weather. At full output the interval between refuels is considerably shorter. Tell us the hours you need lit and we will give you a realistic figure for your site.
Key Features
- Diesel, hybrid and solar options to suit any site
- High-output LED floodlights, up to 345,600 lumens and 12,600 m² of coverage
- Low voltage 48V DC models for more light from the same fuel
- Silent 0 dB(A) battery operation on hybrid and solar models
- Mast heights to 8.4 m with 340° rotation, rated to 110 km/h wind
- Road trailer or compact site frame, for towing or forklift and crane handling
- Liquid containment, darkness sensors, digital timers, anti-glare kits and DSE control systems
Typical Applications
- Mining, shutdowns and remote worksites
- Construction and civil works
- Roadworks and night shifts
- Events, sporting grounds and public spaces
- Emergency response and disaster recovery
- Security, perimeter and car park lighting
Not every model is held in stock, but the full range is available to order. Tell us the site, the hours you need lit and any noise or emissions limits, and we will tell you which lighting tower fits.
